Linear Guides Elements Light Type (Medium Load) For medium loads with stroke speed of up to 10m/s. Light-weight aluminium components and compact dimensions. Roller with bearings, ground raceways of spring steel. For Medium Load   Dynamic Load Range [kN]    2,8 .......... 21,2   Torque [Nm]    25 ............... 806 Weight Type (Heavy Load) a) Linear recirculating roller bearing and guideway b) Six-row linear recirculating ball bearing and guideway a) b) For Heavy Load  Dynamic Load Range [KN]    16,3 .......... 640  Torque [Nm]    303 ............ 4114 Other Types Linear Guides This Section Is Under Construction, We Will Add Technical Data For This Section.
