    enust
    Parallel gripper with sealed 4-sided guides
  • General Explanation
    • Technic Selection Criterions
      Strok per Jaw [mm]  3 ..... 13
      Gripping Force in
    Closing and Opening [N]    		  8,4 ..... 450
      Drive  Pneumatic


    		T-Slot Parallel Grippers
    General Explanation
  • Types and General Technical Data
    • Type Drive : Strok per Jaw [mm] Gripping Force in
    Closing and Opening [N]    		 Detailes
      GP12 Pneumatic   3   8,4 / 4 Detailes
      GP19 Pneumatic   4   36 / 26 Detailes
      GP30 Pneumatic   5   94 / 76 Detailes
      GP45 Pneumatic   5   118 / 155 Detailes
      GP75 Pneumatic   10   220 / 260 Detailes
      GP100 Pneumatic   8 / 13   450 / 450 Detailes
